universal cable tester
The system provides automatic operation diagnosis and automatic correction for the English operation interface, and the system can automatically scan for points.
The system provides advanced short-circuit/conduction tests for unilateral testing/insulation testing.
A variety of test machines are available for purchase, testing high voltage voltages and testing up to 256 test points.
Provide LCD display for continuous testing.
| Item | Symbal | Test Range | |
| Resistance | R | 0.1Ω~10MΩ | |
| Capacitance | C | 10pF~1000μF | |
| Insulation Resistance | I.R | 1MΩ~1000MΩ | |
| Diode | D | 0.0V~7.0V | |
| Conductance | COND | 50mΩ~500Ω | |
| Direct current leakage | IL | 0.1μA~1000μA | |
| High voltage current leakage | IL | 0.1mA~10mA | |
| DC Insulation | IR | 0.1MΩ ~ 1000MΩ | |
| Measuring Frequency and signal / voltage | uA | 100~100KHz，1VAC | |
| Open/Short | O/S | 200Ω~50KΩ | |
| Intermittent O/S | 1KΩ ~ 50KΩ | ||
| Intermittent Cond. | 50mΩ~10Ω | ||
| Low voltage measurement signal | 5VDC,50mA Aax, ±0.5% | ||
